| Group | Shaft | Item No. | Reference with sleeve | Sleeve only splined | Pump type |
| 1 | Cylindrical ∅ 18 | 1 | BCP10 | BMCP1 | GR1 Italian shaft and front flange |
| 2 | Cylindrical ∅ 22 | 2 | BCP20 | BMCP2 | GR2 Italian shaft and front flange |
| 2 | 1/8 taper | 3 | BCP20K | BMCP2 | GR2 Italian shaft and front flange |
| 2 | 1/5 taper | 4 | BCP5280 | - | German front flange, screwdriver shaft |
| 3 | Cylindrical ∅ 26 | 5 | BCP3026* | BMC3 | GR3 Italian shaft and front flange |
| 3 | 1/8 taper | 6 | BCP30K18 | BMC3 | GR3 Italian shaft and front flange |
| 3 | Cylindrical ∅ 45 | - | BCP9G45 | - | 2-hole SAE B front flange and 15-tooth SAE BB splined shaft |
| * Optional complete kit including weld-on plate + PTO shaft 1"3/8 : BCP3026K1 | |||||
1rst item: Cylindrical shaft ∅ 18
centring ∅ 50,8 mm
2nd item: Cylindrical shaft ∅ 22
centring ∅ 50,7 mm
3rd item: Taper shaft 1/8 (∅ 17.5)
centring 50,7 mm
4th item: Taper shaft 1/5
centring 80 mm
5th item: Cylindrical shaft ∅ 26 F6
centring 50,7 mm
6th item: Taper shaft 1/8
centring 50,7 mm
