Danfoss Series H1B Axial Piston Hydromotors

Brand Danfoss

Built as the successor of the well-proven Series 51, the H1B hydraulic motor is even more robust in a compact package.

Product customization

Don't forget to save your customization to be able to add to cart

Quantity

Available to order

Product Tags

Danfoss Axial Piston Hydraulic Motor Motor Hydrostatics High power H1 H1B

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Description
Product Details

Description

State of the art hydrostatic motor from Danfoss in axial piston bent-axis design.
- Keeps all the main benefits of the Series 51 motors, but comes in a smaller size and better efficiency.
- Innovative, new control options available
- The usual product line is extended now with the 210cm3/rev frame size.
- Designed with high power closed circuit drives in mind (but applicable in open circuit as well)

Properties:
- Popular motor family used by the most powerful machinery brands
- Capacity: regulated, max. displacements: 60, 80, 110, 160, 210 or 250 cm3
- Control options include 2-position, prop. and self-controlling versions
- Control input signals can be hydraulic or electric
- 0 degree capability for enabling anti-spin 4-wheel drives
- Speed sensor available
- Different shaft options
- Different hydraulic port options and directions
- Additional options in the Technical Information catalog below
- Good serviceability, with quick delivery of spare parts (in many cases from our stock!)

Application examples:
- Propulsion systems in construction-, agricultural-, forestry and other mobile machinery
- High power shredders, crushers
- High power hydraulic winch drives
- Concrete pumps
- etc.

Danfoss H1B Axial Piston Hydromotors Technical Information

Model of hydromotor	H1B060	H1B080...	H1B110...	H1B160...	H1B210...	H1B250...
Mounting flange	SAE / DIN / cartridge				SAE / DIN	SAE
Hydraulic size [cm³/rev]	60	80	110	160	210	250
Corner Power (theoretical) [kW]	266	321	396	513	609	684
Rated speed (max. - min. - 0 deg. angle) [rpm]	3600 - 5900 - 6600	3200 - 5300 - 5950	2900 - 4800 - 5350	2600 - 4250 - 4750	2350 - 3850 - 4300	2200 - 3650 - 4050
Max. allowable speed (max. - min. - 0 deg. angle) [rpm]	4500 - 7250 - 7950	4100 - 6600 - 7200	3700 - 5950 - 6500	3300 - 5250 - 5750	3000 - 4800 - 5250	2800 - 4500 - 4900
Rated pressure [bar]	450	450	450	450	450	450
Max. intermittent pressure [bar]	480	480	480	480	480	480
Theoretical torque (max. angle) [Nm/bar]	0.96	1.27	1.75	2.55	3.34	3.98
